Gateway installation guide - pole mount

Gateway installation guide - pole mount

The gateway is mounted to a pole via a single hose clamp. The gateway comes with a clamp holder and four M4 screws for installing a hose clamp carrier to the gateway.


Step 1


Position the pole mount holder so that the holes of the pole mount holder coincide with the holes on the back of the Parklio™ Gateway. Use the screwdriver and the provided M4 screws to fix the pole mount holder.

Step 2


Unscrew the hose clamp.

Step 3


Pull the hose clamp through the holes on the sides of the pole mount holder.

Step 4


Wrap the desired spot on the pole with the hose clamp and use the screwdriver to tighten the hose clamp.
